Air FilterKohler Pro Cleaner Air Filter
Anti Scalp Wheels4 Standard
ArmrestsOptional
Blade Design0.164 in. / 0.417 cm Steel with Blade Stiffner
Blade Tip Speed18,908 ft/min / 5,763 m/min
Box Dimensions82.0 in. x 63.0 in. x 52.0 in. / 208.3 cm x 160.0 cm x 132.0 cm
CARB CompliantNot CARB Compliant
Carrier Frame3 in. x 1.5 in. x 0.120 in. (7.6 cm x 3.8 cm x 0.3 cm) Wall Tubular Steel
Caster Tires13 in. x 6.5 in. - 6 in. (33 x 16.5 cm - 15.2 cm) Pneumatic
ClutchElectromagnetic
Comfort PlatformMyRIDE® Suspension System
Cooling SystemAir Cooled
Crankshaft1" (25 mm) w/Steel Protector
Cup HolderStandard
Deck Design10-Gauge Steel IronForged® with Fully Weld Grade 50 Steel Bumper
Deck Material10 Gauge Steel
Deck Size54 in / 137 cm
Discharge ChuteRubber
Drive SystemHydrostatic
Drive Tires22 in. x 11 in. (55.8 cm x 27.9 cm)
Drive TypeRear-Wheel Drive
EngineKohler KT745 26 hp 747cc
Engine BrandKohler
Engine Displacement (cc)747 cc
Engine Horsepower - 26.0 hp
Engine Power (kW) - 19.3 kW
Foot Operated Height of Cut - Standard
Forward Ground/Transport Speed - Up to 8.5 mph / 13.6 kph
Forward Mowing Speed - Up to 8.5 mph / 13.6 kph
Front Bumper - Reinforced Bull-Nose
Fuel Capacity - 5 gal. / 18.9 L / 20 Qt.
Fuel Type - Gasoline
Height of Cut - 1.5 - 5.0 in. / 3.8 - 12.7 cm
Hitch Bracket - Standard
Number of Blades - 3
Product Type - TITAN MyRide
Product Use - Residential
Recommended Oil Type - 10W-30
Roll-Over Protection System (ROPS) - Optional
Seat - 20" Gaming Style
Spindle Housing - Cast-Aluminum
Start Type - Electric
Steering Controls - Twin Lever
Steering Dampeners - Standard Dampers
Terrain Type - Flat with Obstacles
Tires - 13 in. x 6.5 in. (33 x 16.5 cm) Front, 22 in. x 11 in. (55.8 cm x 27.9 cm) Rear
Transmission - Dual hydrostatic HG ZT2800
Weight - 789 lbs / 357.9 kg
